Peripheral Ulcerative Keratitis (PUK)

August 23, 2014

History of Present Illness (HPI)

A 79-year-old woman was referred for the evaluation of a corneal ulcer in the right eye (OD).  She began experiencing foreign body sensation in the right eye about 2 months prior to presentation after getting poked in the eye while gardening.  Since that time, she had experienced pain, tearing, photophobia, and decreased vision in the eye.  The patient was treated with prednisolone acetate 1% drops every 2 hours in the right eye locally, but this was discontinued as corneal thinning was noted.  She was a poor historian but apparently carried a diagnosis of "rheumatoid arthritis" for which she chronically took 5 mg of oral (PO) prednisone daily.  This was increased to 60mg PO daily by her local ophthalmologist about 2 weeks prior to her referral.  She had never seen a rheumatologist.

Past Ocular History

Pseudophakia, both eyes (OU).  History of cataract extraction in both eyes 3 years ago.

Family Ocular History

No family history of rheumatologic or significant ocular disease.

Past Medical History

Hypertension, possible "rheumatoid arthritis," dementia

Ocular medications

Moxifloxacin (Vigamox) twice daily, OD

Systemic medications

Oral Prednisone 60 mg daily for the past 12 days, furosemide, metoprolol

Social History

The patient is retired. She has occasional alcohol use. There is no history of tobacco or illicit drug use.

Review of Systems

Complete review of systems is negative except as in HPI.

Exam

Visual acuity without correction:

OD:  20/200

OS:  20/40+2

Pupils: Equal and round with brisk light response and no relative afferent pupillary defect OU.

Confrontation visual fields: Full to counting fingers OU

Extraocular movements: Full OU

Intraocular pressure (Tonopen):

OD:  17 mmHg

OS:  17 mmHg

Slit Lamp Exam (Figure 1)

OD:

  • Eyelid: Meibomian gland dysfunction
  • Conjunctiva: 1+ injection superiorly
  • Cornea: Crescent-shaped ulceration of peripheral cornea between 11:00 and 3:00 with associated epithelial defect and 80% stromal thinning.
  • Anterior chamber: 3+ cell, trace flare
  • Iris: Normal architecture
  • Lens: Posterior chamber intraocular lens

OS:

  • Eyelid: Meibomian gland dysfunction
  • Conjunctiva: No injection
  • Cornea: Clear and compact
  • Anterior chamber: Deep and quiet
  • Iris: Normal architecture
  • Lens: Posterior chamber intraocular lens

Fundus exam:  Normal OU


A B C

Figure 1:  Slit lamp photographs (A, B) showing a superior, peripheral, crescent-shaped corneal ulcer with 80% corneal thinning OD. There is adjacent conjunctival injection. The fluorescein stain (C) more clearly reveals the area of epithelial defect.


Clinical Course

The patient presented to the University of Iowa Hospitals and Clinics (UIHC) with a peripheral corneal ulceration in the right eye in the setting of arthritis and an unclear history of rheumatologic disease.  The presentation was most consistent with peripheral ulcerative keratitis (PUK) with corneal melt resulting in prominent corneal thinning. The anterior chamber cell and flare was believed to be reactive inflammation secondary to the corneal process.

We contacted her primary care physician who stated she had "polyarteritis" diagnosed 5 years ago that was "rheumatoid factor negative."  In addition to the chronic daily oral prednisone, she was supposed to be taking methotrexate 20 mg every 4 weeks, but regularly missed her appointments for the injections. Her last injection was 8 weeks ago.  She had never seen a rheumatologist.

Blood work for associated systemic conditions was drawn including complete blood count (CBC), blood urea nitrogen (BUN), creatinine, erythrocyte sedimentation rate (ESR), rheumatoid factor (RF), antinuclear antibodies (ANA), antineutrophil cytoplasmic antibodies (ANCA), anti-Ro and anti-La antibodies, and angiotensin-converting enzyme (ACE).  A formal consultation was made with rheumatology. We continued moxifloxacin (Vigamox) BID OD for infection prophylaxis and initiated therapy with cyclosporine 0.05% (Restasis) BID OD and doxycycline 100 mg PO daily for their anti-inflammatory effects. Prednisone was continued at 60 mg PO daily. A bandage contact lens was placed on the eye for comfort.

The laboratory workup was significant for elevated c-ANCA which led to a diagnosis of Wegener's granulomatosis by the patient's local rheumatologist.  She was started back on weekly doses of methotrexate and her prednisone was tapered with resolution of her keratitis.

Discussion

Epidemiology and clinical presentation

Peripheral ulcerative keratitis (PUK) is an inflammatory corneal condition estimated to affect 3 persons per million per year (1).  It predominantly affects older individuals and does not have a significant gender predilection (2,3,4).  The condition may be triggered by surgical or non-surgical trauma, or may arise spontaneously (3).  Patients often present with ocular redness, pain, tearing, photophobia, and decreased vision.  The typical exam finding is a crescent-shaped corneal ulceration (stromal thinning with overlying epithelial defect) located in the peripheral cornea within 2 mm of the limbus (5).  The predilection for the periphery is believed secondary to the close proximity to the conjunctival vessels which supply the inflammatory mediators that cause the disease.  There may be surrounding infiltrate and localized conjunctival injection adjacent to the ulcer.  Cases can be bilateral, but are more commonly unilateral (2,3).  Scleritis occurs simultaneously with PUK in 36-66% of cases.  Necrotizing scleritis is most common and one should be vigilant for this in any patient with both scleritis and PUK (2,3).  Anterior uveitis also frequently accompanies PUK and is present in 9-67% of patients (2,3).

Pathogenesis

PUK is an immunologic condition mediated by both abnormal T-cell and antibody-mediated pathways (6).  It is hypothesized that an abnormal T-cell pathway may produce antibodies that result in immune-complex deposition in the cornea and later activate the complement system and recruit harmful inflammatory cells to the area.  Neutrophils and macrophages then secrete local collagenases and other proteases which cause destruction of the corneal stroma.

Systemic associations

At least half of PUK cases are associated with systemic immune-mediated or rheumatic diseases (1,2). In a quarter of cases, PUK may be the initial manifestation of disease (2). The most common systemic association is rheumatoid arthritis, which is present in 34-66% of patients (2,3,4). In these patients, PUK occurs late in the disease course, with a mean onset 19.6 years after diagnosis (1). PUK develops earlier with Wegener's granulomatosis, often presenting within 6 months of the diagnosis, or precluding the diagnosis as it did in our patient (1).  Other associated systemic conditions include Churg-Strauss syndrome, microscopic polyangiitis, polyarteritis nodosa, relapsing polychondritis, and systemic lupus erythematosus.  Understanding common manifestations of these diseases can be helpful.  For example, a history of epistaxis or sinusitis may be evidence of Wegeners granulomatosis, while a history of asthma or atopy may be present in cases of Churg-Strauss.

PUK can also be associated with local or systemic infectious processes including those caused by bacteria (Staphylococcus and Streptococcus), spirochetes (Treponema pallidum), mycobacteria (tuberculosis), viruses (hepatitis C, herpes simplex virus, varicella zoster virus), Acanthamoeba, and fungi (Table 1)(6).

Table 1: Local and systemic diseases associated with PUK (2,6)

Autoimmune diseases

Vasculitides

Rheumatoid arthritis

Wegener's granulomatosis

Relapsing polychondritis

Systemic lupus erythematosus

Polyarteritis nodosa

Microscopic polyangiitis

Sjögren syndrome

Giant cell arteritis

Churg-Strauss syndrome

Other autoimmune

Graft-versus-host disease

Progressive systemic sclerosis

Infections

Bacterial

Staphylococcus

Streptococcus

Gonococcus

Treponema pallidum

Viral

Herpes simplex virus

Varicella zoster virus

Hepatitis C

Dengue fever

Protozoal

Acanthamoeba

Leishmaniasis

Fungal

Other

Ocular

Traumatic, postsurgical

Metaherpetic

Exposure keratitis

Keratoconjunctivitis sicca

Carcinoma

Dermatologic

Rosacea

Psoriasis

Cicatricial pemphigoid

Stevens-Johnson syndrome

Other systemic

Leukemia

Porphyria

Because of the high association with potentially lethal systemic diseases, all patients with PUK of unknown cause should undergo systemic workup including thorough review of systems in addition to laboratory and radiologic studies (Table 2) (5).

Table 2: Laboratory and radiologic evaluation for patients with PUK (5)

Standard evaluation

Corneal cultures for bacteria, viruses, and fungi

Complete blood count (CBC)

Complete metabolic panel (CMP)

Urinalysis with microscopic analysis (UA with micro)

Antineutrophil cytoplasmic antibody (ANCA)

Antinuclear antibody (ANA)

Rheumatoid factor (RF)

Anticyclic citrullinated peptide (anti-CCP) antibody

Chest radiograph (CXR)

Rapid plasma reagin (RPR)

Fluorescent treponemal antibody absorption (FTA/ABS)

Lyme antibody

Additional tests as guided by history and physical examination

Tuberculin skin test

Sacroiliac joint radiographs

Sinus imaging

Viral hepatitis panel

PUK in association with Wegener's granulomatosis

Wegener's is a small vessel vasculitis that affects mostly the lungs and kidneys.  Pathology demonstrates giant cells with necrotizing granulomas. Classic signs and symptoms include pulmonary infiltrates (71%), sinusitis (67%), epistaxis, rhinorrhea, and hemoptysis.  Vague symptoms are common such as joint pain, fatigue, and weight loss (18).  The American College of Rheumatology (ACR) diagnostic criteria have shown to be 88% sensitive and 92% specific in the diagnosis of Wegener's granulomatosis (Table 3) (19).

Table 3: ACR clinical criteria for the diagnosis of Wegener's granulomatosis (requires 2 of 4)

  • Nasal or oral inflammation
  • Abnormal chest radiograph – fluffy granulomatous infiltrates
  • Urinary sediment – microhematuria or red blood cell casts
  • Granulomatous inflammation on biopsy

Ocular involvement with Wegener's is quite common and is a presenting symptom in up to 16% of cases (Figure 2, Table 4) (18,19).  Children more frequently present with ocular involvement than adults (20).  Ocular involvement has been cited to be as high as 58% at some point in the clinical course (21).


ASuperior epithelial defect with 80% stromal thinning and adjacent sterile corneal infiltrates BSuperior epithelial defect with 80% stromal thinning and adjacent sterile corneal infiltrates CThe eye appears less inflamed with resolution of corneal infiltrates.

Figure 2:  A different patient who was diagnosed with Wegener's granulomatosis after presenting with PUK.  Review of systems revealed a 3-month history of joint pains, generalized fatigue, bloody bowel movements, and sinus discharge.  Lab workup revealed mild normocyctic normochromic anemia with elevated ESR, CRP, and c-ANCA.   The urinalysis showed proteinuria and microhematuria.  (A, B) Superior epithelial defect with 80% stromal thinning and adjacent sterile corneal infiltrates.  (C) Clinical appearance 1 week after initiating treatment.  The eye appears less inflamed with resolution of corneal infiltrates.


Table 4:  Ocular manifestations of Wegener's granulomatosis (23)

  • Orbital inflammation with proptosis
  • Nasolacrimal duct obstruction
  • Scleritis
  • Uveitis
  • Peripheral ulcerative keratitis
  • Retinal vasculitis
  • Cotton wool spots
  • Acute ischemic optic neuropathy
  • Retinal detachment
  • Choroidal detachment

Anti-neutrophil cytoplasmic antibody (ANCA) autoantibodies are very helpful in making the diagnosis of Wegener's.  The c-ANCA test is quite specific for the disease process (93% sensitivity, 97% specificity) (22).  The p-ANCA autoantibody can also be seen with this disease process, but it is also seen in other vasculitides such as microscopic polyangiitis.  Some authors suggest that these autoantibodies can be used for monitoring disease activity as these tests will change with degree of activity of the disease process.  Other common laboratory findings in Wegener's include an elevated ESR, positive rheumatoid factor, and mild normocytic anemia.  Antinuclear antibodies (ANA) are normally negative (18).

Complications

PUK can lead to serious ocular complications (2,3,4,7).  The corneal ulcer can progress rapidly, sometimes leading to corneal melt syndrome (keratolysis) and ocular perforation within days.  This dire complication occurs in 14-35% of cases (4,7).  Around half of patients may require urgent corneal surgery (2,7).  Many of the eyes can be saved, but one report found that nearly 10% of eyes are lost despite treatment (7).  Permanent reduction in vision results from corneal scarring (2,3,4,7).  Between 3-35% have a visual acuity worse than 20/200 at most recent follow-up (4,7).

In addition to the ocular complications, PUK may be a sign of more widespread vasculitis which can cause significant problems with other organ systems and overall mortality of up to nearly 30% (8,9).

Treatment

It is important to recognize and treat patients with PUK due to the high potential for ocular complications and the high mortality rate in the presence of associated systemic disease (8).  Recently, there has been a changing trend in the treatment of autoimmune and vasculitic diseases in which second-line systemic immunosuppressive medications and monoclonal antibody treatments are implemented earlier in the treatment of disease (4,10).

The treatment of PUK depends on the severity of ocular and associated systemic disease.  The primary treatment for acute disease control is systemic corticosteroids, often started at 0.5-1 mg/kg/d with a maximum dose of 60-80 mg daily (5,7,11).  Patients with imminent vision loss may be started initially on pulsed methylprednisolone 1 g/d for 3 days and then transitioned to oral steroids.  The steroids are tapered in accordance with the activity of the disease.  Usually, prednisone is given at a high dose for 2-4 weeks then tapered over the course of several months (18).

An additional immunomodulatory agent is often started concurrently with the corticosteroids in the treatment of PUK.  The choice of immunosuppressive medication depends on the underlying systemic disease process and its severity.  The first-line for rheumatoid arthritis-associated PUK is often methotrexate (5-25 mg once weekly) (9).  If this proves ineffective, other immunomodulatory agents such as cyclophosphamide, azathioprine, cyclosporine, or anti-tumor necrosis factor (TNF) agents may be utilized.  Wegener's granulomatosis may require more powerful immunosuppressive medications for control.  Cyclophosphamide (initial dosage of 2 mg/kg) is often first-line for Wegener's granulomatosis-associated PUK (9).  Azathioprine is a less-effective alternative for those who do not tolerate cyclophosphamide.  In addition to controlling ocular and systemic disease, cytotoxic agents have also been shown to prolong corneal graft survival (12) and reduce overall mortality (8).  Unfortunately, relapse is quite common in these disease processes.

Patients on immunosuppressive medications require frequent exams and blood work to monitor for medication-induced complications. Patients on both corticosteroids and cytotoxic agents should be on prophylaxis against Pneumocystis jiroveci pneumonia (PCP). A common regiment for this is a trimethoprim-sulfamethoxazole single-strength tablet daily (5).  Calcium and vitamin D supplementation and bone density monitoring should be considered for patients on chronic corticosteroids. Rheumatology consultation is usually advised.

Local therapy should include aggressive lubrication and eyelid hygiene, possibly incorporating the use of punctal plugs (9).  Lubrication is useful as many cases have a component of keratoconjunctivitis sicca and it also may dilute inflammatory mediators in the tear film.  Oral doxycycline can assist in ocular surface lubrication through its effects on the Meibomian gland secretions and also has anti-inflammatory effects.  Topical cyclosporine 0.05% (Restasis) has been reported to be successful for non-healing ulcers, likely due to its anti-inflammatory action (13).  Topical corticosteroids suppress corneal inflammation, but they are usually best avoided in cases of PUK as they can contribute to corneal melt by suppressing collagen production.  Topical antibiotics should be utilized for infectious prophylaxis as long as an epithelial defect exists.  The long-term use of moxifloxacin (Vigamox) drops may seem safe due to the lack of preservative, but prolonged exposure to the fluoroquinolone class of antibiotics may actually enhance melting by increasing matrix metalloproteinases in the cornea.  Bacteriostatic antibiotics such as trimethoprim/polymyxin B (Polytrim) may be preferred for long-term use.

In cases of frank or impending corneal perforation, surgical intervention is warranted as a temporizing measure to save the eye.  Surgery alone, however, does not resolve the underlying inflammatory process and does nothing to prevent recurrences of ocular involvement (9). There are multiple surgical options to maintain structural integrity of the globe.  Cyanoacrylate adhesive helps arrest corneal melting by limiting the access of inflammatory cells to the corneal stroma (14).  Penetrating keratoplasty or lamellar grafts can be utilized for structural support or visual rehabilitation (Figure 3, Video 1). Penetrating keratoplasty in patients with PUK has been shown to have a high failure rate, most commonly due to graft melt from PUK recurrence (15,16). Reports have shown 20-40% graft survival at 6 months and many patients therefore require multiple grafts (12,17). Systemic cytotoxic agents reduce the rate of graft failure by treating the underlying inflammatory condition and possibly reducing the rate of endothelial graft rejection (12).  Bandage contact lenses may be utilized in less severe cases or in combination with the above procedures.  Some have advocated for surgical conjunctival resection adjacent to the ulcer to decrease the access of inflammatory cells and factors to the cornea, but this remains controversial as it has not been definitively demonstrated to alter the course of the disease (2,9). Tarsorrhaphy may be helpful if exposure is playing a role.


A leaking descemetocele B leaking descemetocele C appearance after lamellar keratoplasty

Figure 3:  This patient with PUK in the setting of lupus and ocular rosacea presented with a leaking descemetocele (A, B) and underwent a lamellar keratoplasty to restore structural integrity to the eye (C). A video of the surgical procedure can be viewed in video 1.


Video 1: Tectonic anterior lamellar keratoplasty for peripheral corneal perforation in the patient pictured in Figure 2. If video fails to load, use this link.


Diagnosis

Peripheral ulcerative keratitis (PUK) associated with Wegener's granulomatosis

EPIDEMIOLOGY

  • Affects 3 persons per million per year
  • Primarily older adults
  • No gender predilection
  • Half of cases are associated with systemic collagen vascular disease

SIGNS

  • Crescent-shaped peripheral corneal ulceration with overlying epithelial defect
  • May have adjacent infiltrate and localized conjunctival injection
  • Scleritis and anterior uveitis are common associated findings

SYMPTOMS

  • Ocular redness
  • Pain
  • Tearing
  • Photophobia
  • Decreased vision

TREATMENT

  • Local
    • Aggressive lubrication and eyelid hygiene
    • Topical antibiotics
    • Topical cyclosporine 0.05%
    • Bandage contact lens
  • Systemic
    • Oral doxycycline
    • Systemic corticosteroids for acute control
    • Additional systemic immunomodulatory agents are often required for associated autoimmune disease
  • Surgical
    • Cyanoacrylate adhesive
    • Penetrating keratoplasty
    • Lamellar keratoplasty
    • Conjunctival resection
    • Tarsorrhaphy

Differential Diagnosis for Peripheral Ulcerative Keratitis (PUK)

  • Degenerations
    • Terrien's marginal degeneration
    • Pellucid marginal degeneration
    • Furrow degeneration
  • Infectious/inflammatory processes
    • Staphylococcal marginal keratitis
    • Phlyctenular keratoconjunctivitis
    • Vernal keratoconjunctivitis
  • Local factors
    • Exposure keratopathy
    • Neurotrophic keratoconjunctivitis
    • Meibomian gland dysfunction
    • Trichiasis
    • Trauma
    • Surgical complications
    • Poorly fitting contact lenses

References

  1. McKibbin M, Isaacs JD, Morrell AJ. Incidence of corneal melting in association with systemic disease in the Yorkshire region, 1995-7. Br J Ophthalmol. 1999;83:941-943.
  2. Tauber J, Sainz de la Maza M, Hoang-Xuan T, Foster CS. An analysis of therapeutic decision making regarding immunosuppressive chemotherapy for peripheral ulcerative keratitis. Cornea. 1990;9(1):66-73.
  3. Sainz de la Maza M, Foster CS, Jabbur NS, Baltatzis S. Ocular characteristics and disease associations in scleritis-associated peripheral keratopathy. Arch Ophthalmol 2002;120(1):15-19.
  4. Cartwright NE, Tole DM, Georgoudis P, Cook SD. Peripheral ulcerative keratitis and corneal melt: A 10-year single center review with historical comparison. Cornea. 2014;33:27-31.
  5. Galor A, Thorne JE. Scleritis and peripheral ulcerative keratitis. Rheum Dis Clin N Am. 2007;33:835-854.
  6. Dana M, Qian Y, Hamrah P. Twenty-five-year panorama of corneal immunology: emerging concepts in the immunopathogenesis of microbial keratitis, peripheral ulcerative keratitis, and corneal transplant rejection. Cornea. 2000;19(5):625-643.
  7. Malik R, Culinane AB, Tole DM, Cook SD. Rheumatoid keratolysis: a series of 40 eyes. Eur J Ophthalmol. 2006;16:791-797.
  8. Foster CS, Forstot SL, Wilson LA. Mortality rate in rheumatoid arthritis patients developing necrotizing scleritis or peripheral ulcerative keratitis. Effects of systemic immunosuppression. Ophthalmology. 1984;91:1253-1263.
  9. Messmer EM, Foster CS. Vasculitic peripheral ulcerative keratitis. Surv Ophthalmol. 1999;43:379-396.
  10. Resman-Targoff BH, Cicero MP. Aggressive treatment of early rheumatoid arthritis: recognizing the window of opportunity and treating to target goals. Am J Manag Care. 2010;16:S249-S258.
  11. Meyer PAR, Watson PG, Franks W, Dubord P. Pulsed immunosuppressive therapy in the treatment of immunologically induced corneal and scleral disease. Eye. 1987;1:487–495.
  12. Bernauer W, Ficker LA, Watson PG, Dart JK. The management of corneal perforations associated with rheumatoid arthritis. Ophthalmology. 1995;102:1325-1337.
  13. Liegner JT, Yee RW, Wild JH. Topical cyclosporine therapy for ulcerative keratitis associated with rheumatoid arthritis. Am J Ophthalmol. 1990;109:610–612.
  14. Fogle JA, Kenyon KR, Foster CS. Tissue adhesive arrests stromal melting in the human cornea. Am J Ophthalmol. 1980;89:795–802.
  15. Maeno A, Naor J, Lee HM, Hunter WS, Rootman DS. Three decades of corneal transplantation: indications and patient characteristics. Cornea. 2000;19:7-11.
  16. Nobe JR, Moura BT, Robin JB, Smith RE. Results of penetrating keratoplasty for the treatment of corneal perforation. Arch Ophthalmol. 1990;108:939–941.
  17. Messmer EM, Foster CS. Destructive corneal and scleral disease associated with rheumatoid arthritis. Cornea. 1995;14:408–417.
  18. Krachmer JH, Mannis MJ, Holland EJ, Cornea Fundamentals, Diagnosis and Management. Volume 1 [3rd edition]. Mosby Elsevier. pp. 714-716, 1126, 1137-1139.
  19. Leavitt RY, Fauci AS, Bloch DA, Fauci AS, Bloch DA, Michel BA, Hunder GG, Arend WP, Calabrese LH, Fries JF, Lie JT, Lightfoot RW Jr. The America College of Rheumatology 1990 Criteria for the Classification of Wegener's Granulomatosis. Arthritis Rheum. 1990;33:1101–1107.
  20. Levi M, Kodsi SR, Rubin SE, Lyons C, Golden R, Olitsky SE, Christiansen S, Alcorn DM.  Ocular involvment as the initial manifestation of Wegeners granulomatosis in Children. J AAPOS. 2008; 12;94-96.
  21. Fauci AS, Haynes BF, Katz P, Wolff SM. Wegeners granulomatosis: prospective clinical and theraputic experience with 85 patients for 21 years. Ann Intern Med. 1983 Jan;98;76-85.
  22. Cohen Tervaert JW, van der Woude FJ, Fauci AS, Ambrus JL, Velosa J, Keane WF, Meijer S, van der Giessen M, van der Hem GK, The TH. Association between active Wegeners Granulomatosis and Anticytoplasmic antibodies. Arch Intern Med. 1989 Nov; 149:2461-2465.
  23. Bullen CL, Liesegang TJ, McDonald TJ, DeRemee RA. Ocular complications of Wegener's granulomatosis. Ophthalmology. 1983 Mar; 90:279-290.
